Family Datasheet
Product Datasheet
FIB79400v0-ds/os/sc
| Electrical Data | |
| Voltage (V) | 220-240V |
| Frequency (Hz) | 50/60 |
| Input Current (mA) | 92/50 |
| Power Factor (λ) | >0.9 |
| Total Harmonic Distortion | 15% |
| Product Data | |
| Product Wattage (W) | 20/10 |
| Light Source | Integrated LED-3000/4000/5000/6500 |
| Colour Render Index (Ra) | Ra80 |
| Protection Class | CL II |
| Dimmable | No |
| Energy Label | D |
| Operating Temperature | -30°C to +40°C |
| Ambient Temperature Range (Ta) | 25 |
| Switching Cycles (times) | 100,000 |
| Weight (g) | 253 |
| Performance Data | |
| Total Luminous Flux (lm) | 2200/1200 @3000K 2400/1250 @4000K 2400/1250 @5000K 2200/1200 @6500K |
| Luminous Flux (lm) | 2200/1200 @3000K 2400/1250 @4000K 2400/1250 @5000K 2200/1200 @6500K |
| Rated Life (hrs) | 50,000hrs L70B50@Ta25°C |
| IP Rating | IP20 |
| Product Dimensions | |
| Length (mm) | 600 |
| Width (mm) | 75 |
| Height (mm) | 24 |
